| Table dia. | 2250mm | 2830mm | 2830,*3150mm | 3200,*3600mm | 4500mm | 4500mm | 5700mm | 7200mm |
| Max. turning dia. | 2500mm | 3150mm | 4000mm | 4000mm | 5000mm | 5000mm | 6300mm | 8000mm |
| Max. workpiece height | 1600,2000,2500mm | 1600,*2000,*2500mm | 1600,*2000,*2500mm | 1600,*2000,*2500mm | 2000,*2500,*3150mm | 2000,*3150mm | 3150mm | 2500,*3150,*4000mm |
| Max. workpiece weight | 10,*15,*20t | 10,*15,*20t | 15,*20t | 32t | 40t | 65t | 80t | 100t |
| Max. torque of worktable | 63KN.m | 63KN.m | 63KN.m | 80KN.m | 80KN.m | 100KN.m | 250KN.m | 400KN.m |
| Table rotation speed range(16steps) | 2-63r/min | 2-63r/min | 2-63r/min | 2-63r/min | 0.42-45r/min | 0.42-42r/min | 0.42-32r/min | 0.16-16r/min |
| (Vario in 4 or 2 steps) | 0.5-60r/min | 0.5-60r/min | 0.5-60r/min | 1-50r/min | 1-45r/min | 0.42-42r/min | 0.42-32r/min | 0.16-16r/min |
| Max cutting force of the vertical holder | 32KN | 35KN | 35KN | 40KN | 40KN | 50KN | 70KN | 100KN |
| Verticai toolholder move limit | ±30° | ±30° | ±30° | ±30° | ±30° | ±30° | ±30° | ±30° |
| Range of feed rates (18steps) | 0.1-500mm/min | 0.1-500mm/min | 0.1-500mm/min | 0.1-500mm/min | 0.1-500mm/min | 0.1-500mm/min | 0.1-500mm/min | 0.1-500mm/min |
| Horizontal travel of rail head | 1400mm | 1725mm | 2150mm | 2150mm | 2765mm | 2765mm | 3400mm | 4400mm |
| Ram travel of rail head | 1000,*1250mm | 1000,*1250mm | 1000,*1250mm | 1000,*1250mm | 1250,*1600mm | 1250,*1600mm | 1600,*2000mm | 1250,*2000,*2250mm |
| Beam Travel | 1250mm | 1250mm | 1250mm | 1250mm | 2000mm | 2000mm | 2150mm | 2800mm |
| Tool bar section size(WxH) | 40x50mm | 40x50mm | 40x50mm | 40x50mm | 50x50mm | 50x50mm | 50x50mm | 60x60mm |
| Ram section | 240x240mm | 240x240mm | 240x240mm | 240x240mm | 300x250mm | 280x280mm | 280x280mm | 320x320mm |
| Fast moving speed of tool heads | 3500mm/min | 3500mm/min | 3500mm/min | 3500mm/min | 3500mm/min | 3500mm/min | 3500mm/min | 4000mm/min |
| Main motor power | DC/AV:55kw | DC/AV:55kw | DC/AV:55kw | DC/AV:75kw | DC/AV:75kw | DC/AV:90kw | DC/AV:110kw | DC/AV:132kw |
| Overall size(LxWxH) | 7200x5500x4420mm | 7900x6200x4420mm | 8700x6200x4420mm | 8700x6200x4420mm | 9900x8750x5100mm | 9900x8750x5100mm | 11500x9650x6600mm | 13550x11450x7820mm |
| Machine weight | 36t | 38t | 40,*42t | 50,*52t | 67,*69,*72t | 81,*84t | 120t | 195,*215t |
